2块K100-AI卡，使用vLLM运行Qwen3-8B模型，配置tensor-parallel-size为2后，生成速度只有0.1 token/s，DCU利用率只有1.7%，麻烦大佬帮忙看看是什么参数配置不正确吗 注：本来是想运行Qwen3-32B模型，配置tensor-parallel-size为2生成速度特别慢，发现运行Qwen3-8B也一样。Qwen3-8B模型配置tensor-parallel-size为1,生成速度大约30 tokens/s。 ### 配置 系统：Kylin Linux Advanced Server release V11 (Swan25) 驱动：rock-6.3.15-V1.0.1.run CPU：Hygon C86 7470 48-core Processor X 2 MEM：64GB X 4 DCU：Hygon K100_AI 64G X 2 hy-smi --showhw ```text [whkej@localhost models]$ /opt/hyhal/bin/hy-smi --showhw ================================= System Management Interface ================================== ================================================================================================ HCU DID SSID GFX RAS SDMA RAS UMC RAS VBIOS BUS 0 6210 6210 ENABLED ENABLED ENABLED 5.719.001200r.710208 0000:63:00.0 HCU DID SSID GFX RAS SDMA RAS UMC RAS VBIOS BUS 1 6210 6210 ENABLED ENABLED ENABLED 5.719.001200r.710208 0000:a3:00.0 ================================================================================================ ======================================== End of SMI Log ======================================== ``` hy-smi --showproductname ```text [whkej@localhost models]$ /opt/hyhal/bin/hy-smi --showproductname ================================= System Management Interface ================================== ================================================================================================ HCU[0] : Card Series: K100_AI HCU[0] : Card Vendor: Chengdu C-3000 IC Design Co., Ltd. HCU[1] : Card Series: K100_AI HCU[1] : Card Vendor: Chengdu C-3000 IC Design Co., Ltd. ================================================================================================ ======================================== End of SMI Log ======================================== ``` hy-smi --showdriverversion ```text [whkej@localhost models]$ /opt/hyhal/bin/hy-smi --showdriverversion ================================= System Management Interface ================================== ================================================================================================ Driver Version: 6.3.15-V1.0.1 ================================================================================================ ======================================== End of SMI Log ======================================== ``` ### 软件信息 镜像：image.sourcefind.cn:5000/dcu/admin/base/vllm:0.9.2-ubuntu22.04-dtk25.04.2-py3.10 模型：Qwen3-8B docker-compose.yaml ```yaml services: vllm: image: image.sourcefind.cn:5000/dcu/admin/base/vllm:0.9.2-ubuntu22.04-dtk25.04.2-py3.10 container_name: vllm-test environment: - HIP_VISIBLE_DEVICES=0,1 command: > python3 -m vllm.entrypoints.openai.api_server --model /workspace/models/Qwen3-8B --tensor-parallel-size 2 --gpu-memory-utilization 0.9 --served-model-name Qwen3-8B --dtype auto --max-model-len 32768 --trust-remote-code --enforce-eager --host 0.0.0.0 --port 8000 network_mode: host ipc: host shm_size: 64G devices: - "/dev/kfd:/dev/kfd" - "/dev/mkfd:/dev/mkfd" - "/dev/dri:/dev/dri" volumes: - /opt/hyhal:/opt/hyhal - /home/whkej/llm/models:/workspace/models - /sys/kernel/debug:/sys/kernel/debug cap_add: - SYS_PTRACE security_opt: - seccomp=unconfined group_add: - video restart: unless-stopped ``` 测试命令 ```bash curl -X POST "http://127.0.0.1:8000/v1/completions" \ -H "Content-Type: application/json" \ -d '{ "model": "Qwen3-8B", "prompt": "Hello, please introduce yourself", "max_tokens": 50, "temperature": 0.7 }' ``` vLLM运行日志 ```text [whkej@localhost vllm]$ docker compose logs -f vllm-test | _ ____ __ __ ___ vllm-test | | | / / / / / / |/ / vllm-test | | | / / / / / / /|_/ / vllm-test | | |/ / /___/ /___/ / / / vllm-test | |___/_____/_____/_/ /_/ vllm-test | vllm-test | DTK version 25.04.2 vllm-test | vllm version 0.9.2 vllm-test | 2 DCU were detected in the container. vllm-test | NOTE: Make sure the user is in the 39 group. vllm-test | For more information, please go to https://developer.hpccube.com/ vllm-test | INFO 12-28 10:43:39 [__init__.py:245] Automatically detected platform rocm. vllm-test | INFO 12-28 10:43:42 [api_server.py:1395] vLLM API server version 0.9.2 vllm-test | INFO 12-28 10:43:42 [cli_args.py:325] non-default args: {'host': '0.0.0.0', 'model': '/workspace/models/Qwen3-8B', 'trust_remote_code': True, 'max_model_len': 32768, 'enforce_eager': True, 'served_model_name': ['Qwen3-8B'], 'tensor_parallel_size': 2} vllm-test | INFO 12-28 10:43:52 [config.py:850] This model supports multiple tasks: {'reward', 'embed', 'generate', 'classify'}. Defaulting to 'generate'. vllm-test | `torch_dtype` is deprecated! Use `dtype` instead! vllm-test | INFO 12-28 10:43:52 [config.py:1488] Using max model len 32768 vllm-test | INFO 12-28 10:43:52 [config.py:2301] Chunked prefill is enabled with max_num_batched_tokens=2048. vllm-test | WARNING 12-28 10:43:52 [rocm.py:358] To see benefits of async output processing, enable CUDA graph. Since, enforce-eager is enabled, async output processor cannot be used vllm-test | INFO 12-28 10:43:58 [__init__.py:245] Automatically detected platform rocm. vllm-test | INFO 12-28 10:44:00 [core.py:529] Waiting for init message from front-end. vllm-test | INFO 12-28 10:44:00 [core.py:71] Initializing a V1 LLM engine (v0.9.2) with config: model='/workspace/models/Qwen3-8B', speculative_config=None, tokenizer='/workspace/models/Qwen3-8B', skip_tokenizer_init=False, tokenizer_mode=auto, revision=None, override_neuron_config={}, tokenizer_revision=None, trust_remote_code=True, dtype=torch.bfloat16, max_seq_len=32768, download_dir=None, load_format=auto, tensor_parallel_size=2, pipeline_parallel_size=1, disable_custom_all_reduce=False, quantization=None, enforce_eager=True, kv_cache_dtype=auto, device_config=cuda, decoding_config=DecodingConfig(backend='auto', disable_fallback=False, disable_any_whitespace=False, disable_additional_properties=False, reasoning_backend=''), observability_config=ObservabilityConfig(show_hidden_metrics_for_version=None, otlp_traces_endpoint=None, collect_detailed_traces=None), seed=0, served_model_name=Qwen3-8B, num_scheduler_steps=1, multi_step_stream_outputs=True, enable_prefix_caching=True, chunked_prefill_enabled=True, use_async_output_proc=False, pooler_config=None, compilation_config={"level":0,"debug_dump_path":"","cache_dir":"","backend":"","custom_ops":[],"splitting_ops":[],"use_inductor":true,"compile_sizes":[],"inductor_compile_config":{},"inductor_passes":{},"use_cudagraph":true,"cudagraph_num_of_warmups":0,"cudagraph_capture_sizes":[],"cudagraph_copy_inputs":false,"full_cuda_graph":false,"max_capture_size":0,"local_cache_dir":null} vllm-test | WARNING 12-28 10:44:00 [multiproc_worker_utils.py:307] Reducing Torch parallelism from 96 threads to 1 to avoid unnecessary CPU contention. Set OMP_NUM_THREADS in the external environment to tune this value as needed. vllm-test | INFO 12-28 10:44:00 [shm_broadcast.py:289] vLLM message queue communication handle: Handle(local_reader_ranks=[0, 1], buffer_handle=(2, 16777216, 10, 'psm_2bc23870'), local_subscribe_addr='ipc:///tmp/8d3b01da-c213-4f39-b860-01ac76eeb544', remote_subscribe_addr=None, remote_addr_ipv6=False) vllm-test | INFO 12-28 10:44:05 [__init__.py:245] Automatically detected platform rocm. vllm-test | INFO 12-28 10:44:05 [__init__.py:245] Automatically detected platform rocm. vllm-test | WARNING 12-28 10:44:08 [worker_base.py:42] VLLM_RANK1_NUMA is unset or set incorrectly, vllm will not bind to numa! VLLM_RANK1_NUMA = -1 vllm-test | INFO 12-28 10:44:08 [worker_base.py:654] ########## 697 process(rank1) is running on CPU(s): {0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 70, 71, 72, 73, 74, 75, 76, 77, 78, 79, 80, 81, 82, 83, 84, 85, 86, 87, 88, 89, 90, 91, 92, 93, 94, 95, 96, 97, 98, 99, 100, 101, 102, 103, 104, 105, 106, 107, 108, 109, 110, 111, 112, 113, 114, 115, 116, 117, 118, 119, 120, 121, 122, 123, 124, 125, 126, 127, 128, 129, 130, 131, 132, 133, 134, 135, 136, 137, 138, 139, 140, 141, 142, 143, 144, 145, 146, 147, 148, 149, 150, 151, 152, 153, 154, 155, 156, 157, 158, 159, 160, 161, 162, 163, 164, 165, 166, 167, 168, 169, 170, 171, 172, 173, 174, 175, 176, 177, 178, 179, 180, 181, 182, 183, 184, 185, 186, 187, 188, 189, 190, 191} vllm-test | INFO 12-28 10:44:08 [worker_base.py:655] ########## 697 process(rank1) is running on memnode(s): {0, 4} vllm-test | WARNING 12-28 10:44:08 [worker_base.py:42] VLLM_RANK0_NUMA is unset or set incorrectly, vllm will not bind to numa! VLLM_RANK0_NUMA = -1 vllm-test | INFO 12-28 10:44:08 [worker_base.py:654] ########## 696 process(rank0) is running on CPU(s): {0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 70, 71, 72, 73, 74, 75, 76, 77, 78, 79, 80, 81, 82, 83, 84, 85, 86, 87, 88, 89, 90, 91, 92, 93, 94, 95, 96, 97, 98, 99, 100, 101, 102, 103, 104, 105, 106, 107, 108, 109, 110, 111, 112, 113, 114, 115, 116, 117, 118, 119, 120, 121, 122, 123, 124, 125, 126, 127, 128, 129, 130, 131, 132, 133, 134, 135, 136, 137, 138, 139, 140, 141, 142, 143, 144, 145, 146, 147, 148, 149, 150, 151, 152, 153, 154, 155, 156, 157, 158, 159, 160, 161, 162, 163, 164, 165, 166, 167, 168, 169, 170, 171, 172, 173, 174, 175, 176, 177, 178, 179, 180, 181, 182, 183, 184, 185, 186, 187, 188, 189, 190, 191} vllm-test | INFO 12-28 10:44:08 [worker_base.py:655] ########## 696 process(rank0) is running on memnode(s): {0, 4} vllm-test | (VllmWorker rank=1 pid=697) INFO 12-28 10:44:08 [shm_broadcast.py:289] vLLM message queue communication handle: Handle(local_reader_ranks=[0], buffer_handle=(1, 10485760, 10, 'psm_8c0cfe64'), local_subscribe_addr='ipc:///tmp/ea7d80b5-2ae9-4dba-ba04-442a8fb66d98', remote_subscribe_addr=None, remote_addr_ipv6=False) vllm-test | (VllmWorker rank=0 pid=696) INFO 12-28 10:44:08 [shm_broadcast.py:289] vLLM message queue communication handle: Handle(local_reader_ranks=[0], buffer_handle=(1, 10485760, 10, 'psm_713412e6'), local_subscribe_addr='ipc:///tmp/1af32853-eb43-4c7f-ae5e-753f6ea4bff3', remote_subscribe_addr=None, remote_addr_ipv6=False) vllm-test | (VllmWorker rank=0 pid=696) INFO 12-28 10:44:08 [__init__.py:1171] Found nccl from library librccl.so.1 vllm-test | (VllmWorker rank=1 pid=697) INFO 12-28 10:44:08 [__init__.py:1171] Found nccl from library librccl.so.1 vllm-test | (VllmWorker rank=0 pid=696) INFO 12-28 10:44:08 [pynccl.py:70] vLLM is using nccl==2.22.3 vllm-test | (VllmWorker rank=1 pid=697) INFO 12-28 10:44:08 [pynccl.py:70] vLLM is using nccl==2.22.3 vllm-test | (VllmWorker rank=1 pid=697) WARNING 12-28 10:44:09 [custom_all_reduce.py:146] Custom allreduce is disabled because it's not supported on more than two PCIe-only GPUs. To silence this warning, specify disable_custom_all_reduce=True explicitly. vllm-test | (VllmWorker rank=0 pid=696) WARNING 12-28 10:44:09 [custom_all_reduce.py:146] Custom allreduce is disabled because it's not supported on more than two PCIe-only GPUs. To silence this warning, specify disable_custom_all_reduce=True explicitly. vllm-test | (VllmWorker rank=0 pid=696) INFO 12-28 10:44:09 [shm_broadcast.py:289] vLLM message queue communication handle: Handle(local_reader_ranks=[1], buffer_handle=(1, 4194304, 6, 'psm_be253f57'), local_subscribe_addr='ipc:///tmp/17c3c06e-a9ba-4d0a-a628-c71446862ef4', remote_subscribe_addr=None, remote_addr_ipv6=False) vllm-test | (VllmWorker rank=0 pid=696) INFO 12-28 10:44:09 [parallel_state.py:1077] rank 0 in world size 2 is assigned as DP rank 0, PP rank 0, TP rank 0, EP rank 0 vllm-test | (VllmWorker rank=1 pid=697) INFO 12-28 10:44:09 [parallel_state.py:1077] rank 1 in world size 2 is assigned as DP rank 0, PP rank 0, TP rank 1, EP rank 1 vllm-test | (VllmWorker rank=1 pid=697) INFO 12-28 10:44:09 [gpu_model_runner.py:1819] Starting to load model /workspace/models/Qwen3-8B... vllm-test | (VllmWorker rank=0 pid=696) INFO 12-28 10:44:09 [gpu_model_runner.py:1819] Starting to load model /workspace/models/Qwen3-8B... vllm-test | (VllmWorker rank=1 pid=697) INFO 12-28 10:44:10 [gpu_model_runner.py:1824] Loading model from scratch... vllm-test | (VllmWorker rank=0 pid=696) INFO 12-28 10:44:10 [gpu_model_runner.py:1824] Loading model from scratch... vllm-test | (VllmWorker rank=1 pid=697) INFO 12-28 10:44:10 [rocm.py:288] Using Flash Attention backend on V1 engine. (only supports block size 64) vllm-test | (VllmWorker rank=0 pid=696) INFO 12-28 10:44:10 [rocm.py:288] Using Flash Attention backend on V1 engine. (only supports block size 64) Loading safetensors checkpoint shards: 0% Completed | 0/5 [00:00
